Bench Top Controller


Bench Top Controller

The BT-15 Controller is a Single Zone PID Temperature Controller, featuring easy, auto-tune programming and solid state output, in a rugged metal enclosure.

The BenchTop unit has rugged simplicity to get you results without learning a custom programming language. This controller is ideal for most laboratory or industrial heating control requirements.

HTS/Amptek BBA Series Controllers are designed to offer maximum ease of use with pinpoint accuracy. Temperature range may be set in degrees Fahrenheit or Celsius with 1° or 0.1° resolution. Advanced functions may be unlocked to access proportional, integral, and derivative values as well as other variables.

Standard BT-15 Controllers offer a maximum load capacity of 15 amps at 120 or 240VAC. Customized options and configurations are available. “Click” the CUSTOMIZED button or contact the factory for more functionality.


PID Control: 1/16 DIN, Single, Closed Loop Process Zone
Enclosure: Metal Enclosure W/ Rubber Feet (5 by 6 by 7 in.)
Accuracy: +/- 1°, +/-0.25% of Full Scale
Sensor Input: Thermocouple (J/K/T/R/S) or RTD (100Ω)
Display: 7 Segment LED Process & Setpoint
Single Output: SSR (0 Fired), 15A. 120 or 240 VAC
Resolution: 1° or 0.1°, Selectable
Power Lead: 6ft SO Cord with NEMA Plug
